| 產品名稱：美國TransducerTechniques稱重傳感器，變送器TM0-1，TM0-1，TM0-1 |
| 產品類型：美國TransducerTechniques稱重傳感器 |
| 產品編號：TM0-1 |
| 產品價格： |
發郵件索取產品資料：[email protected]
 |
|
| |
| |
| |
|
美國TransducerTechniques稱重傳感器，變送器TM0-1，TM0-1，TM0-1
AMPLIFIER SECTION |
0755-26738637 13045855010王小姐 |
|
|
Type: |
|
Bipolar, differential |
|
Gain Range: |
|
75 to 1000 |
|
Input Sensitivity: |
|
1 mV/V minimum |
|
|
|
|
|
for 8 VDC output
|
Output Voltage: |
|
0 to ±8 VDC (linear to 9.5) |
|
Output Current: |
|
0 to 10 mA | |
|
|
|
Nonlinearity: |
|
.01% maximum |
|
Accuracy: |
|
±.05% of FS |
|
Stability: |
|
±.1% for 24 hours |
|
Tempco: |
|
.01% full scale/°C |
|
Noise and Ripple: |
|
Less than 5 mV P-P at |
gain=1000
|
Filter Type: |
|
2 Pole Butterworth |
|
Frequency Response: |
|
DC to 220 Hz (2.2, 22, |
2200 Hz available, no
charge)
|
BRIDGE SECTION |
|
|
|
Excitation Voltage: |
|
8 VDC ±.25 V 5 VDC optional |
|
Sensor Resistance: |
|
120 ohm minimum |
|
|
|
|
|
1000 ohm maximum
|
Balance Range: |
|
±30% of output (350 ohm |
bridge)
|
GENERAL |
|
|
Weight: |
|
Approx. 2 ozs. |
|
Size: |
|
2.25"L x 2.50"W x .80"H |
inches tall
|
Mounting: |
|
Corner standoffs, 4-40 thread |
|
Input/Output: |
|
Via screw terminals |
|
Operating Temp: |
|
0 to 70 °C |
|
Power Required: |
|
12 VDC ± .5V at 65 mA |
|
Mounting Footprint: |
|
2.012 x 2.227 |
所有型號
TM0-1
TMO-1-2.2
TMO-1-22
TMO-1-2200
TMO-1-22
